Fiberglass 3240/G10 electrical insulation Epoxy Fiberglass laminate Sheet

Short Description:

3240 Epoxy Glass Fiber has the following physical characteristics and properties:
1.Temperature resistance:Grade B
2.High dielectric constant.
3.High strength and wear resistance.
4. Resistant to aggressive environments.
5. Weather resistance,hygroscopicity.
6. It is very suitable for mechanical processing
7.Thickness: 0.8mm-80mm.

Send email to us Contact Us

Product Detail

Product Tags

Thickness:0.1mm-120mm Length:1020*2020mm 1220*2040mm 1220*2440mm
Color:Red(other colors can becustomized)
3240 Epoxy fiber glass cloth laminated sheet:dip alkali-free glass fiber cloth in epoxy phenolic resinthen bake and heat press.It has good mechanical and dielectric properties with thermostability and moisture resistivity and good machinabilityThe thermostability grade is B. It is widely used in generator,motorelectronic apparatus as insulating material and components. It is also suitable under oil pressure of transformer and wet environment.

Compliance with standards:
In accordance with GB/T 1303.4-2009 electrical thermosetting resin industrial hard laminates : IEC 60893-3-2-2011 insulating materials – electrical thermosetting resin industrial hard laminates – Part 3-2 of the individual material specification EPGC201.
